Shenzhen Risingstar Outdoor High Light LCD Co., Ltd
Shenzhen Risingstar Outdoor High Light LCD Co., Ltd
Bränd: Tõusvlcd
Tootlikkus: 1250k
Päritolukoht: Shenzhen
Sertifikaat: CE/ROSH/UL/ISO9001
Shenzhen RisingStar 10,1 tolli 1000 NIT TFT LCD -paneel, originaal AUO/BoE/Innolux LCD -moodul, pealaua link LCD -paneeliga on ühendatud paneeli liidesega läbi paneelirea. Erinevad LCD -paneelid kasutavad erinevaid liidese vorme. RisingStar 10,1 tolli 1000 nits tft LCD paneel on peamiselt LVDS -liides.
Pareeter
| Size | 10.1inch |
| Panel item | RS101NET-N10 |
| Panel type | a-Si TFT-LCD |
| Display mode | IPS,Normally black，transmissive display |
| Pixels | 1280*800 |
| brightness | 350-1000cd/m2 |
| Constrast Ratio | 800:1 |
| Response Time | 14/11ms |
| View angle | 85/85/85/85 |
| View area | 218.96*137.6mm(H*V) |
| Dispaly area | 218.96*137.6mm(H*V) |
| Outline Size | 230.7*152.55*7mm(H*V*D) |
| Signal Type | LVDS |
| Working freqyency | 60Hz |
| Working temperature | -20~70ﾟC |
| Storage Temperature | -25~70ﾟC |
| Display ratio | 16:9 |
| Display color | 16.7m |
| Backlight Voltage | 3.3V |
| Backlight Power Consumption | 6.18w |
| Surface Treatment | Haze |
| Weight | 0.375kgs |
Kuumad sildid: 10,1 tolli 1000 NIT TFT LCD -paneel, Hiina, tehas, odav, hind, kohandatud, tsitaat, aken suunas LCD, hele LCD -paneel, välistingimustes televiisor, Sunlight LCD -paneel, kõrglahutusega LCD -tahvel, välistingimustes kasutatav digitaalne reklaam, 65 -tolline reklaam, 65 -tollised reklaamid LCD -ekraan
