Size: 10.1 inch
Brightness: 1000 nits
Contrast Ratio: 1000:1
Resolution: 1280*800
Operating Temperature: -10 - 50°C
Väikese suurusega manustatud välistingimuseks, 10,1 tolli TFT 1000 NITS LCD Monitor. Ekraanil kuvatavat sisu saab selgelt näha hästi valgustatud keskkonnas, seda saab kasutada igasuguste laadimisvaiade, iseteeninduse müügiautomaatide, kioskite ja muude serveriterminalide abil.
Kui teil on muid vajadusi, võtke meiega ühendust, kohandame vastavalt teie vajadustele kõige sobivamat vedelkristallide ekraanilahendust.
Manustatud välistingimuseks on tootefunktsioon
10.1 "TFT LCD paneel
1280*800 resolutsioon
Õues kasutatud, heledus 500 nitist kuni 1500 niti valikuline
Mahtuvuslik puutepaneel, mis on kaetud 2 mm karastatud klaasist tahke ja usaldusväärse vandaali tõendi jaoks
VGA HDMI DVI USB -liides
Suure jõudlusega pealaua, 7/24 pidev töö
Toetage 12-24 V lai pinget
Ülikerge esiosa raam 3mm, ideaalne manustatud paigaldamiseks
Esipaneel IP55 veekindel tolmu ennetamine
Lai temperatuuri töö: -10 - 50 ° C
|
Product specification |
|
|
LCD panel |
|
|
Panel size |
10.1" |
|
Resolution |
1280*800 or 1024*600 |
|
Support Color |
16.7M colors |
|
Brightness (cd/m²) |
1000 nits (can be customized) |
|
Contrast ratio |
1000:1 |
|
View angle |
80°/80°/80°/80° (R/L/U/D) |
|
Touch panel |
|
|
Touchscreen Type |
Capacitive Touch (10 points ) |
|
Surface Hardness |
7H |
|
Luminousness |
90% |
|
Touch Interface |
USB (RS232 optional) |
|
Touch response time |
2ms |
|
Working Life |
>50 million times |
|
OSD |
|
|
OSD control |
Brightness, contrast ratio, auto adjustment, H/V position, language select, etc. |
|
Support languages |
English, French, Spanish, Portuguese, Italian, German, Russian, Japanese, Chinese, etc. |
|
Support OS |
Windows ,HDMI, Android, ect. |
|
Power Supply |
|
|
External Power Supply |
AC 100 - 240V, 50-60Hz |
|
Working voltage |
DC 12-24V |
|
Power consumption |
≤35W |
|
Enclosure |
|
|
Material |
Aluminum Alloy |
|
Color |
Black, Silver or customized |
|
VESA mounting |
75x75mm/100x100mm |
|
IP grade |
Front panel IP55 waterproof |
|
Operating Environment |
|
|
Temperature Range |
operating: -10 to 50°C, storage: -20 to 80°C |
|
Relative humidity |
operating: -5% to 95%, storage: -5% to 95% |
|
Packing Details |
|
|
Gross weight |
about 4kg |
|
Accessories |
Power adapter, VGA cable, USB touch cable, embedded screws |
|
Other |
|
|
Mounting |
embedded mounting screws |
|
wall mounting brackets (optional) |
|
|
desk stand holder (optional) |
|
|
Warranty |
1 year warranty |
|
Certificates |
CE, 3C, RoHS |
